Code produit : VF--CHDCC-CHD16-CU
Nominal diameter: DN15 ～ DN300
Nominal pressure: 1.6MPa ～ 32.0MPa
Applicable temperature: - 29 º C~+570 º C
Valve body material: WCB, carbon steel, chrome molybdenum vanadium steel, stainless steel
Applicable medium: water, oil, steam, gas
Structural form: cut-off
Connection mode: welding, flange
Drive mode: handwheel, bevel gear, electric
Manufacturing standards: GB, German DIN, American API, ANSI
Please contact us if you need customized services. We will contact you with the price and availability in 24 hours.
| Produit | Code produit | Pureté | Taille | Nous contacter |
Main Features and Uses:
1. The valve and pipeline are connected by welding structure.
2. The sealing surface is not easy to wear and scratch, with good sealing performance and long service life.
3. Compact structure, good opening and closing performance, small height and convenient maintenance.
4. It is suitable for water, steam and oil pipelines, and has the characteristics of high temperature resistance and high pressure resistance.
Technical standards for manufacturing acceptance:
1. The technical conditions for manufacturing acceptance shall comply with JB/T3595 or E101.
2. The valve structure length shall comply with ANSI B16.10 or E101.
3. The valve body welding groove shall comply with ANSI B16.25 or the size provided by the user.
The welding stop valve is applicable to the pipeline of various systems in petroleum, chemical, hydraulic and thermal power plants with nominal pressure of PN20 ～ 32MPa, P54/100V-P57/170V and working temperature of ≤ 540 ℃ (wherein the working temperature of P57/170V is 570 ℃), cutting off or connecting the pipeline medium, including water, oil, steam, etc. Operation modes: manual, gear drive, electric, etc.
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
